Double Conic
Typical Applications
- Outdoor Classroom
- Play Area
- Shaded Focal Point
- Drop Off/Pick up Area
- Alfresco Dining
Size Options
- 7m x 4m, 9m x 6m
- 11m x 8m, 18m x 10m
Image Gallery >
| Dimensions(m) | L | W | h1 | H |
|---|---|---|---|---|
| 7 x 4 | 7 | 4 | 2.3 | 4 |
| 9 x 6 | 9.3 | 6.2 | 2.3 | 4.9 |
| 11 x 8 | 11 | 8 | 2.5 | 5.2 |
| 18 x 10 | 18 | 10 | 3.5 | 6.9 |
Double Conic
Provides exceptional coverage with minimal interruption to landscaping. Multi-functional design is ideal for any situation; from educational and healthcare to commercial and retail use.
Supporting Steel & Framework: Mild steel legs, galvanised or polyester powder coated to any RAL colour. Marine grade (316) stainless steel fittings.
Installation: Typically a 1 day install on to concrete foundation pads. Requires clear access for plant equipment during installation. Recommended equipment: Cherry picker or scaffold tower, telehandler.
Installation: Typically a 1 day install on to concrete foundation pads. Requires clear access for plant equipment during installation. Recommended equipment: Cherry picker or scaffold tower, telehandler.
Fabric Canopy Options
| PVC | SGW | |
|---|---|---|
| Lifespan | 20 Years | 30 Years |
| Solar Protection | 100% of harmful rays | filters UVB + UVC but allows UVA for plant growth |
| Light Transmission | Up to 10% | Up to 20% |
| Recyclable | Yes | Yes |
